Holographic Polyester Powder Coated Aluminium Ral 7032 7047 For PV Photovoltaic

Brand Name:	JIA ZHEN
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	50000TONS/YEAR

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001; SGS; ROHS

Anti-theft Window Series:

Strong Anti-corrosion Ability, Strong Anti-corrosion Ability, Scratch And Impact Resistance, Environmentally Friendly And Pollution-free, Long Service Life.

Photovoltaic Bracket Series:

Super Corrosion Resistance, Excellent Weather Resistance, High And Low Temperature Resistance.

Packaging Details:

Inner packing :polyethylene bag; Outer packing :paper carton

Highlight:

PV polyester powder coated aluminium

Ral polyester powder coated aluminium

Holographic ral 7032 powder coating

Product Description

The Core Function of Black Powder Coating for PV Mounting Structures

The core function of black powder coating for PV (photovoltaic) mounting structures is to provide long-term anti-corrosion protection and aesthetic enhancement, while also delivering physical properties suitable for harsh outdoor environments.

This is a very precise observation. As the load-bearing and supporting structure of a PV system, the performance of the surface coating on PV mounting structures directly affects the service life of the entire system. Black is one of the most mainstream color choices.

Core Performance Requirements

PV mounting structures are exposed to outdoor conditions for long periods, enduring sunlight, rain, salt spray (in coastal areas), temperature fluctuations, and other challenges. Therefore, their powder coatings must meet the following key performance criteria:

Superior Corrosion Resistance: This is the most core performance requirement. The coating must pass a Neutral Salt Spray (NSS) test for over 1000 hours, or even meet higher standards, to prevent rusting or corrosion of the mounting structure base material (mostly aluminum alloy or steel).

Excellent Weather Resistance: It should resist long-term UV radiation to avoid fading, chalking, cracking, or other issues on the coating. Generally, after a 2000-hour artificial accelerated aging test (QUV), the color difference and gloss change of the coating must stay within allowable ranges.

Good Physical and Mechanical Properties: These include high adhesion (reaching Grade 0 or Grade 1 in the cross-cut test), impact resistance (withstanding a certain level of impact without peeling), and wear resistance. These properties address minor collisions and friction during installation and use.

High and Low Temperature Resistance: The coating must remain stable within the extreme temperature range of -40℃ to 80℃, without softening, embrittlement, or peeling.

Main Applications and Values

Protecting the Base Material and Extending Mounting Structure Lifespan: By forming a dense, uniform coating on the surface of the mounting structure, it isolates the base material from corrosive media such as air, moisture, and salt. This extends the service life of the mounting structure from several years to over 20 years, matching the design life of the PV system.

Optimizing Appearance and Recognition: The black coating has a uniform, attractive appearance, which enhances the overall visual uniformity of the PV power station. Meanwhile, black is a neutral color that blends better with the surrounding environment (such as rooftops and the ground).

Enhancing Environmental Adaptability of Mounting Structures: For different application scenarios (such as coastal areas, plateaus, and deserts), the coating formula can be adjusted to enhance specific properties (like salt spray resistance and UV resistance), ensuring the stable operation of the mounting structure in various harsh environments.

Meeting Safety and Environmental Standards: High-quality black powder coatings contain no solvents and have extremely low VOC (Volatile Organic Compounds) emissions, complying with environmental requirements. Additionally, the coating itself is non-flammable and does not release toxic substances, meeting the safety standards of power stations.

Key Differences from Coatings of Other Colors

In the application of PV mounting structures, besides color differences, black powder coatings mainly differ from light-colored coatings in heat absorption. However, this characteristic has little impact on PV mounting structures.


			Comparison Dimension

			Black Powder Coating

			Light-colored (e.g., white, light gray) Powder Coating

			Core Advantages

			Good dirt resistance (stains are less visible), uniform appearance

			High reflectivity, low heat absorption

			Applicable Scenarios

			Most general scenarios, power stations with high appearance requirements

			High-temperature areas with special heat dissipation requirements (less common)

			Limitations

			Relatively high heat absorption (minimal impact on the mounting structure)

			Prone to showing dirt, more obvious appearance changes after long-term use

In summary, various colors and effects can be customized according to customer requirements!

Our Advantage

1, Epoxy powder coating: offer the best corrosion protection.
2, Polyester powder coating: offer the highest exterior stability and performance.
3, Our products applied to indoor and outdoor.
4, Our products with SGS,Tuv, Rohs,TDS, MSDS, Certificate.


F&Q
Q:What color are available to me?

A:We usually carry a very large range of colors. Has access to over 300 paint color and texture. Feel to call us and ask if we stock your required color. If not we can customize.

Q:Are all the colors the same price?

A:NO. Some colors are more expensive due to their availability. Ingredients, such as texture powders, candies, metallic, glow in dark powders.

Q:Where can I find pricing information?

A:Our pricing structure is dependant on volume, technology and color choice. Please contact us for specific product pricing.

Q:Need more info?

A:We would love to help you with your Powder Coating questions and of course we look for ward to doing business with you. Let us know how we can help you.

Q:What kind of payment terms you can accept?
A:We accept PayPal, T/T , LC,and Western Union
